Line Arrangement in Case of Self-Levelling Device, a S D & 4MATIC® for 1986 Mercedes-Benz 300E
No.
Part # / Description / Price
Price
8
MSRP $3.90
$2.99
11
Clamp
Mercedes-Benz
Mercedes-Benz Description: FROM STEERING GEAR ON COOLING LINEInside diameter: 17mmMaterial thickness: 0,6mmWidth across flats: SW7Model 1: W1. CONNECTORInside diameter: 17mmMaterial thickness: 0,6mmWidth across flats: SW7Model 1: W1. FROM OIL PUMP TO HEIGHT CONTROL VALVEInside diame ...
MSRP $5.25
$4.03
MSRP $5.25
$4.03
11
Hose Clamp Mercedes-Benz
Mercedes-Benz Description: Return line to radiator. From steering to cooling pipe. Connection piece. Hose to radiator 15.5 mm. Hose to pipe. From pump to steering. Low pressure hose. From return line to fuel tank. Oil connection hose.
36
MSRP $115.00
$86.25
37
Pressure Line Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: From control valve to ring cylinder.
41
Hydraulic Line Mercedes-Benz
Mercedes-Benz Description: Connection "t", from control valve to oil reservoir. (return line),connection "t", from control valve to t-fitting.
44
Line Mercedes-Benz
Mercedes-Benz Notes: TO BE ADAPTED DURING ASSEMBLY
Description: (return line),from self-levelling unit to coupling piece.
MSRP $107.00
$80.00
MSRP $107.00
$80.00
45
Retaining Screw Mercedes-Benz
Mercedes-Benz Description: M12x1. Line connection. Brake line. Hydraulic line. Lines m 12x1. Dia., 6,3 . M 12. 620mm. From brake master cylinder to hydraulic unit.
MSRP $0.90
$0.65
MSRP $0.90
$0.65
47
Connection Piece Mercedes-Benz
Mercedes-Benz Description: M12. To separation point. Line connection. Lines. Pressure line. From high pressure expansion hose to distributor valve.
50
Line Mercedes-Benz
Mercedes-Benz Notes: TO BE ADAPTED DURING ASSEMBLY
Description: (return line) from coupling piece to oil reservoir. From high pressure expansion hose to coupling piece. From high pressure expansion hose to control valve. From pump to service valve. (return line) from distributor to distributor. From master cylinder,connection "h",to hydraulic unit,connection: "h",teves. High-pressure line to connection fitting. From distributor to oil tank.
MSRP $63.00
$47.25
MSRP $63.00
$47.25
59
Line Mercedes-Benz
Mercedes-Benz Notes: TO BE ADAPTED DURING ASSEMBLY
Description: (return line) from coupling piece to oil reservoir. Connection "t", from control valve to coupling piece.
74
Hose Mercedes-Benz
Mercedes-Benz Description: From spring load accumulator to right hydropneumatic spring leg.
MSRP $210.00
$150.00
MSRP $210.00
$150.00
77
Sealing Ring Mercedes-Benz
Mercedes-Benz Description: CONNECTING HOSE TO HYDROPNEUMATIC SPRING LEGStrength / hardness class: CUInside diameter: 12mmOutside diameter: 16mmMaterial thickness: 1,5mm. 7 speed auto. SRREW PLUGStrength / hardness class: CUInside diameter: 12mmOutside diameter: 16mmMaterial thicknes ...
MSRP $4.70
$3.64
MSRP $4.70
$3.64
80
Banjo Bolt Mercedes-Benz
Mercedes-Benz Description: BETWEEN VALVE,TRANSFER CASE AND CYLINDER COVER,VACUUMDiameter: 12mmStrength / hardness class: STThread code letter: MThread pitch: 1,5mmWidth across flats: 17mm. LONGITUDINAL LOCK BREATHERDiameter: 12mmStrength / hardness class: STThread code letter: MThre ...
MSRP $38.50
$29.90
MSRP $38.50
$29.90
